KATHMANDU
PRO

SRP* 1179 EUR

ArtNo. 862310

Comparison

OUT IN
THE WORLD

Attention to detail is a CUBE obsession. That's why, with the Kathmandu's Integrated Carrier 3.0, we designed it to work seamlessly with our ACID mudguard. We've fitted a flat mount for the rear disc brake – it also accommodates the kickstand – and used Smooth Welding to give the frame joints a tidy, organic appearance. But it's not all about looks. We also equipped the rear end with a thru axle and added a tapered head tube for improved rigidity and steering precision, even when fully laden. With Internal Cable Routing to keep your gear shifts smooth with minimal maintenance, we reckon we've thought of everything. Just don't forget your toothbrush.

Frame Material

Aluminium Superlite

Ruggedness and elegance don't often go hand in hand, but the Kathmandu Pro from CUBE is the exception that proves the rule. With its Integrated Carrier 3.0, Smooth Welding and Internal Cable Routing, it's as practical as it is great to look at. And the flat mount kickstand, ACID mudguards and lighting set mean you're all set for anything. Where to next?

KATHMANDU

The Integrated Carrier 3.0 is the next level in system integration: from the side, it's hard to tell where the luggage carrier ends and the mudguard begins. But it doesn't just look good, it's also incredibly strong and rigid. With an integrated spring clamp and CUBE Rilink ready adaptor for mounting bags and baskets, it transforms your CUBE into an adaptable and versatile load carrier.

Our trekking series is designed to take you wherever your curiosity leads you. So, of course, you'll want a comfortable ride. With a natural feeling seated position and handling that's stable and reassuring with or without a load, Trekking Comfort Geometry does exactly what it says no matter how much experience you have of cycling.

Smooth Welding isn't easy, but worthwhile things usually aren't. It has two advantages. First, and most obviously, it looks great: one tube seems to almost flow into the other. Second, and at least as importantly, it helps to minimise load peaks on welded areas for better frame strength and durability.

Cables for your gears and brakes are essential, but you don't necessarily want to see them all the time. Our semi internal cable routing takes gear and brake cables through the down tube for a cleaner appearance, smoother shifts and reduced maintenance. So your CUBE bike looks good and continues to function as it should, and you just concentrate on enjoying the ride.

CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.

Frame

frame

Aluminium Superlite, Trekking Comfort, Integrated Carrier 3.0, Double Butted

size

Classic: XS / 46cm, S / 50cm, M / 54cm, L / 58cm, XL / 62cm

Suspension

Suspension fork

SR Suntour NCX D LO Air, 63mm, Lockout

Drivetrain & brakes

brake system

Shimano BR-MT200/UR300, Hydr. Disc Brake, PM/FM (160/180)

rear derailleur

Shimano Cues RD-U6020-SGS, 10-Speed

shifters

Shimano Cues SL-U6000, Rapidfire-Plus

front derailleur

Shimano Cues FD-U6010, Top-Swing, 31.8mm

bottom bracket

Shimano BB-MT501, 68mm BSA

crankset

Shimano Cues FC-U6000, Hollowtech ll, 46x30T, Chainguard

cassette

Shimano Cues CS-LG400, 11-39T

chain

KMC xGlide

Cockpit

headset

VP Integrated, Top 1 1/8", Bottom 1 1/2"

Stem

CUBE Performance Stem Pro, 31.8mm

handlebar

CUBE Comfort Trail Bar, 680mm

grips

ACID Travel Comfort

Wheels

rims

CUBE EX25, 32H, Disc, Tubeless Ready

front hub

Shimano DH-3D37, Hub Dynamo, QR, Centerlock

rear hub

Shimano FH-TC500-HM, 12mm Through Axle, Centerlock

tyres

Schwalbe Marathon Green, Perf, 47-622

Finishing kit

saddle

ACID Sequence Pro 160

seat post

CUBE Performance Post, 27.2mm

pedals

CUBE PP MTB

front light

CUBE Shiny 50

rear light

ACID Mudguard Rear Light PRO-D, 6V, AC

kickstand

ACID FM Pure Kickstand

mudguards

ACID 56 Integrated Carrier 3.0

bell

Easy Bell

carrier

ACID Integrated Carrier 3.0, CUBE Adapter Compatible

Product information

colour

silverblue´n´grey

weight

16,9 kg

Art. No

862310

SRP*

1179 EUR

*Suggested retail price

Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

140
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	46 cm	50 cm	54 cm	58 cm	62 cm
Seat tube	460	500	540	580	620
Top Tube Horizontal	558	569	583	598	613
Seat angle	73°	73°	73°	73°	73°
Head tube angle	70°	70°	70°	70°	71°
Chainstays	455	455	455	455	455
Head tube	113	133	153	173	193
Wheelbase	1067	1079	1094	1110	1114
BB-Height to Hub	60	60	60	60	60
Protrusion height - 80mm	785	817	848	879	911
Reach	374	380	388	397	405
Stack	601	620	638	657	681

Ergonomics

	46 cm	50 cm	54 cm	58 cm	62 cm
Stem length	90	90	90	90	90
Angle stem	17°	17°	17°	17°	17°
Handlebar width	700	700	700	700	700
Crank length	170	170	175	175	175
Length seat post	350	350	350	350	350
Diameter seatpost	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	728	728	728	728	728
Width tire maximum	48	48	48	48	48

All values are given in millimetres or degrees.

CUBE's designers ensured the Kathmandu Pro to have everything you need and nothing that you don't. From the elegant simplicity of the Integrated Carrier to the full-length mudguards, front and rear lights and CUBE FM kickstand, it's the practical everyday companion that's rugged enough to take on longer trips, too. A Suntour air suspension fork makes even the roughest roads smoother, for a more comfortable ride. Schwalbe tyres use recycled rubber, to reduce their environmental impact. Shimano's Cues 2x10 gears give you the range you need to make light work of any route. And Shimano hydraulic disc brakes ensure you can always stop safely, no matter what you're carrying or what the weather is throwing your way. Urban jungle or distant horizon, the Kathmandu Pro has got your back.
