STEREO ONE22 C:62
TM 29

SRP* 2999 EUR

ArtNo. 835300

Comparison

THE
ATHLETE

When you have something great already, the trick is to refine it – and that's exactly what we've done here. The Stereo ONE22 C:62 frame takes our renowned mid-travel suspension concept and reimagines it with our Advanced Twin Mold C:62® carbon construction. There's an angle-adjustable headset, so you can tweak the Agile Trail Geometry to suit your riding style. A pair of ISCG tabs makes it easy to fit a chain device, while Internal Cable Routing complements the frame's organic appearance. And, with the UDH interface, you can look forward to long-lasting, ultra-reliable gear shifting. It's got it all covered.

Frame Material

C:62®

Frame weight

1950 g

Angle Adjustment

0,6°

A Trail Motion bike is a special bike in any CUBE line-up, and the Stereo ONE22 C:62 TM is no exception. With our Advanced Twin Mold C:62® carbon frame technology and the pick of trail-worthy components, it's your guarantee of a good time off-road.

More Information

Bike category of use: 4

You can find more information about Bike Classification at the following link.

More Information

115
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

Slack/Moderate	S	M	L	XL
Seat tube	370	405	420	470
Top Tube Horizontal	566 / 567	594 / 596	622 / 624	653 / 655
Seat angle	76.2° / 76°	76.2° / 76°	76.2° / 76°	76.2° / 76°
Head tube angle	65.4° / 66°	65.4° / 66°	65.4° / 66°	65.4° / 66°
Chainstays	431	431	431	431
Head tube	90	100	110	130
Wheelbase	1161 / 1154	1190 / 1183	1219 / 1212	1253 / 1245
BB-Height to Hub	41 / 40	41 / 40	41 / 40	41 / 40
Protrusion height - 80mm	729 / 733	739 / 743	737 / 741	770 / 774
Reach	427 / 426	452 / 451	477 / 476	502 / 501
Stack	603 / 605	612 / 614	621 / 623	639 / 641

Ergonomics

	S	M	L	XL
Stem length	40	40	50	50
Handlebar width	760	760	760	760
Crank length	170	170	170	170
Length seat post	403	460	510	510
Diameter seatpost	30.9	30.9	30.9	30.9
Stroke seatpost	120	150	170	170
Diameter tire maximum	758	758	758	758
Width tire maximum	64	64	64	64
Rear suspension travel	120	120	120	120

All values are given in millimetres or degrees.

A great trail bike is only as good as its suspension components. We know that, which is why for the Stereo ONE22 C:62 TM we began with a 130mm Fox 34 Float Rhythm fork at the front, and paired it with a Fox Float Performance at the rear. Smooth, progressive and easily adjustable, they're the perfect trail companions. Grippy Maxxis Forekaster 2.4in tyres rolling on Newmen Beskar 30 wheels are held in check by Shimano's powerful XT hydraulic disc brakes. And Shimano's peerless XT 1x12 gears get your power to the trail with flawless ratio changes, shift after shift after shift. Ready to ride?
